Whether you want to fly past traffic, add a few miles to your fitness regime or just get some fresh air, the FX is ready for it all. Our most popular hybrid bike family is designed to give you the durability, comfort and control you need to get outside and enjoy your time pedalling.
Shimano CUES
Inspired by rider demand for trouble-free drivetrain longevity and performance, Shimano CUES offers a new foundation for versatility and durability across a range of both electric and standard bikes. CUES features Shimano’s new LINKGLIDE drivetrain technology for significantly increased life on wear items like chain, cassette and chainrings.
Shimano LINKGLIDE
LINKGLIDE technology has been specifically engineered for incredible durability while still delivering smooth and decisive shifting – along with a great pedalling experience. Available exclusively on Shimano CUES drivetrains.
Upgrade your pedals and love your bike more
Pedals are two of the five touchpoints that connect you with your bike, and even though this bike comes with a pair, upgrading to pedals that boost control and grip will greatly improve your ride. See the pedal guide and find the best pedals for your riding style. We recommend flat pedals for simple versatility.
| Frameset |
| Frame |
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR |
| Fork |
FX alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR |
| Wheels |
| Hub front |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
| Skewer front |
139x5 mm bolt-on |
| Hub rear |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer rear |
152x5 mm QR |
| Rim |
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
| Tyre |
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm |
| Drivetrain |
| Shifter |
Shimano U4000, 9-speed |
| Rear derailleur |
Shimano CUES U4000 |
| Crank |
ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length |
| Bottom bracket |
Sealed cartridge, 68 mm |
| Cassette |
Shimano LINKGLIDE LG300, 11-46, 9-speed |
| Chain |
Shimano LG500 |
| Pedal |
Bontrager City pedals |
| Components |
| Saddle |
Bontrager Sport Women's |
| *Seatpost |
Size: S, M Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm lengthSize: XL, L Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length |
| *Handlebar |
Size: S, M Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm widthSize: XL, L Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width |
| Grips |
Trek Line Ergonomic Comp, lock-on |
| *Stem |
Size: S, M Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm lengthSize: XL, L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
| Brake rotor |
Tektro wave, 6-bolt, 160 mm |
| Brake Set |
Tektro HD-R280 hydraulic disc, 160 mm rotor |
| Weight |
| Weight |
M - 11.95 kg / 26.35 lbs |
| Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
