Whether you want to fly past traffic, add a few miles to your fitness regime or just get some fresh air, the FX is ready for it all. Our most popular hybrid bike family is designed to give you the durability, comfort and control you need to get outside and enjoy your time pedalling.
Upgrade your pedals and love your bike more
Pedals are two of the five touchpoints that connect you with your bike, and even though this bike comes with a pair, upgrading to pedals that boost control and grip will greatly improve your ride. See the pedal guide and find the best pedals for your riding style. We recommend flat pedals for simple versatility.
| Frameset |
| Frame |
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR |
| Fork |
FX steel, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR |
| Wheels |
| Hub front |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
| Skewer front |
139x5 mm bolt-on |
| Hub rear |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer rear |
152x5 mm QR |
| Tyre |
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm |
| Drivetrain |
| *Shifter |
Size: S, XL, XS, L, M Shimano EF500, 2-speedSize: S, XL, XS, L, M Shimano EF500, 8-speed |
| Front derailleur |
Shimano Tourney TY606, 31.8/34.9 mm clamp, top swing, dual pull |
| Rear derailleur |
Shimano Acera M3020-8, 40T max cog |
| Crank |
Forged alloy, 46/30, 170 mm length |
| Bottom bracket |
Sealed cartridge, 68 mm |
| Cassette |
Shimano 8-speed, 12-32T |
| Chain |
KMC Z8.3 |
| Pedal |
Wellgo nylon platform |
| Components |
| Saddle |
Bontrager Sport |
| *Seatpost |
Size: S, XS, M Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm lengthSize: XL, L Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length |
| *Handlebar |
Size: S, XS, L, M Bontrager Riser, steel, 25.4 mm, 30 mm rise, 600 mm widthSize: XL Bontrager Riser, steel, 25.4 mm, 30 mm rise, 620mm width |
| Grips |
Trek Line Ergonomic Comp, lock-on |
| *Stem |
Size: S, XS, M Bontrager alloy, 25.4 mm clamp, 10-degree, 90 mm lengthSize: XL, L Bontrager alloy, 25.4 mm clamp, 10-degree, 110 mm length |
| Brake |
Tektro MD-U310 mechanical disc |
| Brake rotor |
Tektro wave, 6-bolt, 160 mm |
| Weight |
| Weight |
M - 13.00 kg / 28.67 lbs |
| Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
