Short Description
The Trek Fuel EX 5 Gen 5 is a versatile full-suspension trail mountain bike built for riders ready to tackle technical climbs, fast descents and demanding singletrack. Featuring a lightweight Alpha Platinum aluminium frame, 140mm front suspension and Shimano Deore 12-speed drivetrain, it delivers confident performance and outstanding value for trail riding.

Key Features

• Frame: Alpha Platinum Aluminium full-suspension frame with ABP suspension system
• Suspension: RockShox Recon Silver RL fork (140mm) & X-Fusion Pro 2 rear shock
• Drivetrain: Shimano Deore 1×12 wide-range gearing
• Brakes: Shimano hydraulic disc brakes
• Dropper Post: Internally routed dropper seatpost
• Geometry: Adjustable Mino Link trail geometry

Product Overview
The Fuel EX 5 Gen 5 is Trek’s do-everything trail bike, combining efficient climbing ability with confident descending performance. Its proven ABP suspension design keeps the rear suspension active under braking for improved traction and control, while modern trail geometry delivers stability on technical terrain. With long-travel suspension and dependable Shimano Deore components, this bike is ideal for riders stepping into full-suspension trail riding.

Specifications

• Frame: Alpha Platinum Aluminium, ABP, Boost148, Control Freak internal routing, Knock Block
• Rear Travel: 130mm
• Fork: RockShox Recon Silver RL, Solo Air, Motion Control damper, 140mm travel
• Rear Shock: X-Fusion Pro 2
• Wheel Size: 29" (M–XL)
• Wheels: Tubeless-compatible alloy wheels
• Tyres: Bontrager XR4 / Maxxis Rekon approx. 2.6"
• Drivetrain: Shimano Deore M6100 12-speed
• Cassette: 10-51T
• Crankset: Shimano MT511, 30T
• Brakes: Shimano hydraulic disc brakes (MT200 series)
• Seatpost: TranzX internally routed dropper post
• Handlebar: Bontrager alloy, 750mm
• Weight: Approx. 15.7 kg (size M)

Ideal For

• Trail and all-mountain riding
• Technical singletrack and descents
• Riders upgrading to full suspension

What’s Included

• 1 × Trek Fuel EX 5 Gen 5 Full Suspension Mountain Bike

Care & Notes
Professional setup recommended before riding. Suspension servicing and drivetrain maintenance should be carried out regularly for optimal performance. Specifications may change due to manufacturer updates.
