Frame Scale Carbon HMF
Adjustable head angle, Syncros Cable Integration System
Advanced Shock & Standing Damping System
BB92, UDH Interface, 12x148mm with 55mm Chainline
Fork RockShox Judy Silver TK Solo Air15x110mm QR axle, 51mm offset, Tapered SteererReb. Adj., Lockout, 110mm travel
Remote System SCOTT RideLoc TechnologySuspension & Dropper Remote2 Suspension modes
Rear Derailleur Shimano Deore RD-M6100 SGSShadow Plus, 12 Speed
Shifters Shimano Deore SL-M6100-R, Rapidfire Plus
Crankset Shimano FC-MT512-155mm CL, 32T
BB-Set Shimano BB-MT500, shell 41x92mm
Chain Shimano CN-M6100
Cassette Shimano Deore CS-M6100-12, 10-51 T
Brakes Shimano MT200 Disc Brake
Rotor Shimano SM-RT10 CL, 180/F and 160/R
Handlebar Syncros Alloy 6061T shape Flat, 9°, 740mmSyncros Performance XC lock-on grips
H'stem Syncros DC 3.0Syncros Cable Integration System0° rise, 6061 Alloy, 31.8mm, 1 1/8"
Seatpost Syncros Duncan Dropper, 31.6mmS size 100mm, M size 130mm, L &XL size 150mm
Seat Syncros Belcarra Regular 2.5
Headset Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)Formula CL-811, 15x110mm
Hub (Rear)Formula CL-548M, 12x148mm, Micro Spline
SpokesStainless Black 15G, 1.8mm
RimsAlex X-25/ 32H, 25mmTubeless ready
Front TireMaxxis Rekon Race, 29x2.4", EXO, Tubeless Ready
Rear TireMaxxis Rekon Race, 29x2.4", EXO, Tubeless Ready
Approx weight in KG12.9 (Tubless setup)
Approx weight in LBS28.44 (Tubless setup)
Max. System Weight130kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
