| Frame |
OCLV Mountain Carbon, IsoBow, tapered head tube, internal routing, balanced post-mount brake, Boost148 |
| Fork |
RockShox Judy GOLD, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
| Max compatible fork travel |
120 mm |
| Hub front |
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle |
| Hub rear |
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle |
| Rim |
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve |
| *Tyre |
Size: S, M, ML, L, XLBontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40" |
| |
Size: S, M, ML, L, XLBontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.20" |
| Max tyre size |
Frame: 29x2.40", Fork: See manufacturer |
| Shifter |
Shimano Deore M6100, 12-speed |
| Rear derailleur |
Shimano Deore M6100, long cage |
| *Crank |
Size: S, M, MLShimano MT512, 32T, 55 mm chain line, 170 mm |
| |
Size: L, XLShimano MT512, 32T, 55 mm chain line, 175 mm |
| Bottom bracket |
Shimano MT500, 92 mm, PressFit |
| Cassette |
Shimano Deore M6100, 10-51, 12-speed |
| Chain |
Shimano Deore M6100, 12-speed |
| Max. chainring size |
1x: 38T |
| Saddle |
Verse Short, chromoly rails, 145 mm width |
| *Seatpost |
Size: SBontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length |
| |
Size: M, ML, LBontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length |
| |
Size: XLBontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
| *Handlebar |
Size: SBontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
| |
Size: M, ML, L, XLBontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width |
| Grips |
Bontrager XR Trail Comp, nylon lock-on |
| *Stem |
Size: SBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
| |
Size: M, MLBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
| |
Size: LBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
| |
Size: XLBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
| Head set |
FSA IS-2, 1-1/8" top, 1.5" bottom |
| Brake |
Shimano MT200 hydraulic disc |
| *Brake rotor |
Size: S, M, ML, L, XLShimano RT10, CenterLock, 160 mm |
| |
Size: L, XLShimano RT10, CenterLock, 180 mm |
| Rotor size |
Max brake rotor sizes – Frame: 180 mm, Fork: see fork manufacturer |
| Weight |
M - 12.13 kg / 26.75 lbs (with TLR sealant, no tubes) |
| Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
