| Main Frame |
Fuji A1-SL Alloy front and rear triangle w/ mounting for down tube battery, 1 1/8” head tube, post disc mount, replaceable hanger |
| Fork |
HL VASA 28S 525 AMS 27.5, travel 100mm |
| Crankset |
Shimano TY301, 48/38/28T, w/ chainring guard |
| Bottom Bracket |
Bafang cadence sensor bottom bracket |
| Pedals |
Nylon platform, chromoly axle |
| Front Derailleur |
Shimano Tourney TY710 |
| Rear Derailleur |
Shimano Altus M310 |
| Shifters |
Shimano Altus M310, Rapid Fire |
| Cassette |
Shimano Acera HG31, 11-32T, 8-speed |
| Chain |
KMC X8 w/ Missing Link, 8-speed |
| Wheelset |
Shimano TX505 CL disc, 36H, front / Bafang motor hub, 6 bolt disc, 36H, rear, stainless steel spokes, aluminum double wall rims |
| Tires |
Vera Eos, 27.5” x 2.2”, 30tpi |
| Brakeset |
Shimano MT200 hydraulic disc, rotors: 180mm front, 160mm rear |
| Brake Levers |
Shimano MT200 hydraulic disc 3 finger levers |
| Headset |
1 1/8”, Zero Stack, caged bearings |
| Handlebar |
Oval Concepts riser bar, 6061 alloy, 15mm rise, 5-degree sweep, 31.8mm clamp |
| Stem |
6061 aluminium, +/- 6 degree rise, 31.8mm clamp |
| Tape/Grip |
Oval Concepts 234 Trail, single density Kraton |
| Saddle |
Oval Concepts 300P, steel rail |
| Seat Post |
Oval Concepts, 6061 alloy micro adjust, 30.9mm diameter |
| Drive Unit |
Bafang H400B rear hub motor, 250W rated power 25kph maximum assist, 45Nm |
| Battery |
Fuji Power Pack 417Wh w/ 2A charger |
| Display |
Bafang 5 mode LED display w/ walk assist |
| Misc |
Alloy kickstand, bell |
| Derailleur Hanger |
D002 |
| Weight |
21.14 kg |
